Water Electrolysis Hydrogen Generation Plant For Optical Fiber Enterprises

Water Electrolysis Hydrogen Generation Plant For Optical Fiber Enterprises

    • Water Electrolysis Hydrogen Generation Plant For Optical Fiber Enterprises
    • Water Electrolysis Hydrogen Generation Plant For Optical Fiber Enterprises
  • Water Electrolysis Hydrogen Generation Plant For Optical Fiber Enterprises

    Product Details:

    Place of Origin: china
    Certification: ISO9001;2008

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Packed in standard export packing
    Delivery Time: 60working days after received your payment
    Supply Ability: 100sets per month
    Contact Now
    Detailed Product Description
    Application: Industry Purity: 99.9%
    Feature: Long Service Life Low Energy Consumption Type: Hydrogen
    H2 Output: 500m3/h

    99.9% 500 m3/h purity  Hydrogen Generation Plant
    Specifications:



    Description:


    1, Parameters:(  DQ-500/1.6 Hydrogen generating plant by water electrolysis  )
    1.1 Type:            DQ-500/1.6

    1.2 Rated H2 output:         500m3/h

    1.3 Rated O2 output:         250m3/h

    1.4 Purity of H2 from outlet:        ≥99.9%

    1.5 Purity of O2 from outlet::         ≥99.3%
    1.6 System working pressure :       1.6Mpa
    1.7 Moisture contained in H2:          ≤4g/Nm3H2
    1.8 Rated DC consumption        ≤ 4.5KWh/Nm3H2
    1.9 Control method:            PLC+ upper computer (or touch screen)

    2,System utility and consumption

    2.1 Power supply

    No.

    Power

    Frequency

    Voltage

    Phase

    Position

    Remark

    1

    4000KVA×3

    50Hz

    10KV

    3-phase

    Rectification transformer



    2

    60kw

    50Hz

    380v

    3-phase,4-wire

    Control panel

    2.2 Cooling water

    2.2.1 Quantity requirement :Pressure :0.3-0.4MPa Tmept.:≤32℃  Hardness<4German degree

    2.2.2 Quantity used for the equipment

    No.

    Qt.

    Equipment

    Remark

    1

    35 m3/h

    Generator of hydrogen

    Recycling use



    2

    4m3/h

    Rectification panel for H2 generating

    Recycling use

    2.2.3Raw water  pure water :resistance rate:5 megohm

    2.2.4 Quantity:

    500L/h   Plant

    2.3   KOH quality requirement in electrolyte

    2.3.1  Potassium hydroxide purity required higher than analyzing degree

    2.3.2 Potassium hydroxide quantity needed:                                   7000Kg (provided by user)

    2.4. Instrument gas

    2.4.1 Quality:Oil content<5mg/m3    Dust granularity <20μm    Dew point 10℃ lower than ambient tempt.

    2.4.2 Quantity:

    No.

    Quantity

    Pressure

    Equipment

    Remark



    3m3/h

    0.6MPa

    Generator of hydrogen





    the can produce hydrogen,oxygen and other gas purification equipment,and can also produce high purity gas purification equipment.The equipment manufactured by THEhas the following advantages:
    1.Advanced flow process
    Flow process of using product gas as regeneration gas for producing high purity gas.
    Flow process with no feed gas consumption.
    Flow process comnined the two above mentioned process,with little consumption of feed gas and obtained higner purity product gas.
    2.high purity
    through one step purification,the purity can reach to 99.999-99.9999%
    impurity conent ,like H2/O2 can reach to 1ppm,dew point can reach to 0.1ppm,dew point can reach to lower than -90°C(0.1ppm).
    3.Little consumption of regeneration gas
    Compared with the normal consumption of 20%.the consumption of purifier manufactured by THE is only 5-12%
    4.Relliable and safety
    All of the valves, important instruments and components are produced by famous manufactures all over the word.
    5.Compact structure,little apace occupation.


    Applications:


    Hydrogen gernerating plant by water electrolysis is widely used in the field of power plants, electronic industry, semi-conduct material factories, optical fiber enterprises, metallurgy, building material factories, atomic industry, space flight, chemistry, weather broadcasting station, medicine industry, etc.


    Competitive Advantage:
    We have exported to Indian, Vietnam , Nigeria , Pakistan , Indonesia , Korea , Iran , etc.
    Hydrogen equipment by electrolyzing varies from 5 m3/h to 600 m3 /h, pressure from 0.5MPa to 5MPa. Our factory has gained ISO9001 certificate. We have gained many patents and our technical data reached world advanced level and some of them rank at the front of the world.
