Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm

Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm

    • Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm
    • Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm
    • Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm
  • Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm

    Product Details:

    Place of Origin: Hangzhou,China
    Brand Name: Tailian
    Certification: ISO,CE
    Model Number: WDZJ-A 3*1600

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: nogotiation
    Packaging Details: wooden case
    Delivery Time: 2 month after payment
    Payment Terms: L/C, T/T
    Supply Ability: 100 sets per month
    Contact Now
    Detailed Product Description
    Plate Thickness: 0.5-3.0mm Plate Width: 500-1600mm
    Number Of Strips Produced: 15-30 Pcs Slitting Speed: 0-120m/min
    Weight Of Raw Steel Coil: <25t Floor Area: 28*8m
    Condition: New Place Of Origin: Hangzhou,China



    Round Disc Slitting Machine Set 0.5-3.0 Plate Thickness Plate Width 500-1600mm





    1.description



    WDZJ-A series round disc slitting machine set is a production line composed of coiling,ponch and primary leveling.slitting and coiling equipments.



    The equipment set is designed to vertically slit the raw steel coil into the final steel coils with the requiredwidth,which is the raw material of rolling,tube-welding,cold forming and punching processes.



    Configured with the cutters of different material,the equipment set is able to vertically slit various kinds of nonferrous metals.



    2.Soft materials

    Several methods are available for soft materials like plastic films, textiles, adhesive tapes, and paper. Razor blades, straight, or circular blades are being used. Some blades cut through the material while others crush the material against a hard roll. Those are similar to knives. The cutting blades can be set to a desired width. Some machines have many blades and can produce a number of output rolls at once. The slit material is rewound on paper, plastic or metal cores on the exit side of the machine.

    The process is used because of its low cost and high precision for mass production. Some machines have a program that monitors the blades and sharpens the blades often to maintain the quality and precision of the cut. Depending on the industry and the product that is being slit these machine can run between 10m/min (special metal webs) and 5000 m/min (paper making process). The machines can also incorporate extensive automation to precisely control material tension, automatically position the slitting knives, automatically align the cores onto which the material is wound and to reduce manual handling of the rolls.

    Examples of materials that can be cut this way are: adhesive tape, foam, rubber, paper products, foil, plastics (such as tarps and cling wrap), glass cloth, fabrics, release liner and film.



    3.Machinery

    For metal coils, the slitter consists of three main parts: an uncoiler, slitter, and recoiler.[3] The material is fed from the uncoiler, through the nip between the two circular cutting wheels (one on top and another underneath), and then re-wound in slit pieces on the recoiler.

    When the term "slitter rewinder" or "slitting machine" is used to describe the machine, the three parts are referred to as the unwind, the slitting section and the rewind. Slitter rewinders are normally used to slit plastic films, paper and metal foils. The unwind stage holds the roll stably and allows it to spin; it is either braked or driven to maintain accurate tension in the material. Some machines have a driven unwind which reduces the effect of inertia when starting to unwind heavy rolls or when the material is very tension-sensitive.

    The slitting section has three main options:

    • Razor slitting, which is ideal for thin plastic films – the system is very simple and quick to set. Although the razor blades are of low cost, they need to be frequently changed to ensure a good quality slit edge.
    • Rotary shear slitting. Male and female circular knives engage to give a scissor cutting effect. This system is used widely on paper, films and foils. Although the knives take longer to position, they stay sharp longer than razor blades. The setting time can be reduced by using an automatic knife-positioning system.
    • Crush cut slitting. A male knife runs against an anvil. The system works well with certain materials including non-wovens and foams.

    The rewind section also has options. The main type is centre winding using differential rewind shafts. These shafts are becoming universal on most slitting machines. The differential shafts ensure an even tension across the full width of the material. Closed-loop control of the winding tension using feedback from load cells provides the total tension-control system required for running tension-sensitive materials. Precise and accurate tension control is the key to good roll slitting. Modern machines use AC vector drives with closed-loop feedback from AC motors. When used with the correct control algorithms, they produce excellent results with the minimum of maintenance.



    condition new
    plate thickness 0.5-3.0mm
    plate width 500-1600mm
    number of atrips produced 15-30 pcs
    slitting speed 0-120m/min
    weight of eaw steel coil <25t
    floor area 25*8m
